If you would like to use metal Top and Bottom Plates please read more about this application update in our Blog Post: Similar feature is already added to another our BIM solution, Metal Framing Wall+. The latest versions of Wood Framing Wall+ from now support Curved Wall. Here are some of the changes in our BIM solution Wood Framing Wall+ you should know about:ġ. Hello there! Today we introduce you a sizeable update release that is relevant to all wood-frame house designers. I used the architecture template.FebruRenata Jočienė What’s New in Wood Framing Wall+ 2016.10? Start a new project using a default out-of-the-box (OOTB) template.Note that Screencast allows for audio narration as well if you turn a mic on. Ideally, as you do these steps, use Screencast to capture the video (so you can post here if further assistance is needed).
